KPG375C
KING POWER
8502120000
Genset model: King Power/KPG375C | Installation Method: Fixed |
Fuel type: Diesel | Cooling Method: Water Cooling |
Conditions of use: Land use | Usage: Common/standby units |
Excitation Mode: AC Rotating Exciter | Excitation Mode: AC Rotating Exciter |
Output Type: AC Three Phase | Stroke: Four Stroke |
Trademark: King Power | Out-put Power(KW/KVA): 300/375 |
Origin: Shenzhen, China | Dimension(MM):3420*1050*1650 |
Sound Level(DB): 60-105 | Gross weight(KGS): 2950 |
Speed(RPM): 1500/1800 | Engine brand&Model:NTA55-G1A |
HS code: 8502120000 | Advantage: Anti-Vibration, Fuel-saving, high Efficiency |
Alternator brand: Robot/Marathon/Leroy-somer | |
Optional Parts: Parallel System, Fuel Tank, wheels, ATS | |
Standard Accessory: Exhaust Silencer, Flexible Pipe, Battery Cables, battery, air breaker | |
Environment: Work in Any Kinds of Harsh Climate | |
Warranty Period: 1 Year or 1000 Hours from the genset's delivery from the seller, subject to whichever comes first. |
Genset model: King Power/KPG375C | Installation Method: Fixed |
Fuel type: Diesel | Cooling Method: Water Cooling |
Conditions of use: Land use | Usage: Common/standby units |
Excitation Mode: AC Rotating Exciter | Excitation Mode: AC Rotating Exciter |
Output Type: AC Three Phase | Stroke: Four Stroke |
Trademark: King Power | Out-put Power(KW/KVA): 300/375 |
Origin: Shenzhen, China | Dimension(MM):3420*1050*1650 |
Sound Level(DB): 60-105 | Gross weight(KGS): 2950 |
Speed(RPM): 1500/1800 | Engine brand&Model:NTA55-G1A |
HS code: 8502120000 | Advantage: Anti-Vibration, Fuel-saving, high Efficiency |
Alternator brand: Robot/Marathon/Leroy-somer | |
Optional Parts: Parallel System, Fuel Tank, wheels, ATS | |
Standard Accessory: Exhaust Silencer, Flexible Pipe, Battery Cables, battery, air breaker | |
Environment: Work in Any Kinds of Harsh Climate | |
Warranty Period: 1 Year or 1000 Hours from the genset's delivery from the seller, subject to whichever comes first. |
Genset features
1. Engine and alternator shall be mounted on a same frame steel skid.
2. Built-in damper for anti-vibration.
3. World-famous diesel engine brand.
4. World-famous AC alternators brand.
5. Intelligent and reliable control module.
6. Full range protection function and alarm shutdown feature.
7. Supply of all the necessary spare parts.
8. High price performance ratio.
9. After-sale service centers located all over the world.
Alternator Feature
1. Brush-less, 4 poles, rotation magnet.
2. IP21-23) enclosure is standard for all industrial alternators.
3. The insulation system is Class H
4. Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts.
5. Wide range of flange adapters and single bearing disc coupling.
6. Standard 2/3 pitch windings avoid excessive neutral currents
7. AVR auto voltage regulator, auto exciter, auto adjustment
ATS System
If the generator set will be used as a standby power, the auto transfer switch (ATS) is necessary and essential. Because ATS can automatically transfer load from Mains power to generator set. In normal, when the Main power fails or voltage drops below 80% of the normal voltage, ATS will auto start standby generator set after a preset time of 0-10 sec (adjustable according to the users). Once generator reaches at rated speed, the ATS will transfer the load to standby generator sets automatically.
Genset features
1. Engine and alternator shall be mounted on a same frame steel skid.
2. Built-in damper for anti-vibration.
3. World-famous diesel engine brand.
4. World-famous AC alternators brand.
5. Intelligent and reliable control module.
6. Full range protection function and alarm shutdown feature.
7. Supply of all the necessary spare parts.
8. High price performance ratio.
9. After-sale service centers located all over the world.
Alternator Feature
1. Brush-less, 4 poles, rotation magnet.
2. IP21-23) enclosure is standard for all industrial alternators.
3. The insulation system is Class H
4. Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts.
5. Wide range of flange adapters and single bearing disc coupling.
6. Standard 2/3 pitch windings avoid excessive neutral currents
7. AVR auto voltage regulator, auto exciter, auto adjustment
ATS System
If the generator set will be used as a standby power, the auto transfer switch (ATS) is necessary and essential. Because ATS can automatically transfer load from Mains power to generator set. In normal, when the Main power fails or voltage drops below 80% of the normal voltage, ATS will auto start standby generator set after a preset time of 0-10 sec (adjustable according to the users). Once generator reaches at rated speed, the ATS will transfer the load to standby generator sets automatically.
1.Q: What is your minimum order quantity for this product?
A: 1 set.
2. Q: What is your generator power range?
A: 10kw-5000kw.
3. Q: Is it okay to make the customer's own brand?
A: We can be your OEM manufacturer.
4. Q: What is the delivery time?
A: The fastest 15 working days after receiving the 30% T/T deposit.
5. Q: Where is your loading port?
A: Shenzhen port or according to customers' requirement.
6. Q: What is your company's available production capacity?
A: 500 units per year.
7.Q: What is the warranty period?
A: 12 months after shipment or 1000 working hours.
1.Q: What is your minimum order quantity for this product?
A: 1 set.
2. Q: What is your generator power range?
A: 10kw-5000kw.
3. Q: Is it okay to make the customer's own brand?
A: We can be your OEM manufacturer.
4. Q: What is the delivery time?
A: The fastest 15 working days after receiving the 30% T/T deposit.
5. Q: Where is your loading port?
A: Shenzhen port or according to customers' requirement.
6. Q: What is your company's available production capacity?
A: 500 units per year.
7.Q: What is the warranty period?
A: 12 months after shipment or 1000 working hours.
